26 / 33 page  ANALOG INTERFACES Symbol Parameter Test Condition Min. Typ. Max. Unit IMIC Input Leakage GND < VMIC <VCC -100 +100 µA RMIC Input Resistance GND < VMIC <VCC 50 k Ω RLVFr Load Resistance VFr+ to VFr- 100 Ω CLVFr Load Capacitance VFr+ to VFr- 150 nF ROVFr0 Output Resistance Steady zero PCM code applied to DR; I = + 1mA 1.0 Ω VOSVFr0 Differential offset: Voltage at VFr+,VFr- Alternating + zero PCM code applied to DR maximum receive gain; RL = 100 Ω -100 +100 mV RLLS Load Resistance LS+ to LS- 50 Ω CLLS Load Capacitance LS+ to LS- 600 nF ROLS Output Resistance Steady zero PCM code applied to DR; I + 1mA 1 Ω VOSLS Differential offset Voltage at LS+, LS- Alternating + zero PCM code applied to DR maximum receive gain; RL =50 Ω –100 +100 mV RLTRO Load Resistance at TRO TRO to GND 600 Ω POWER DISSIPATION Symbol Parameter Test Condition Min. Typ. Max. Unit ICC0 Power down Current CCLK,CI = 0.4V; CS = 2.4V ( µwire only) All other inputs active GCI mode only: 0.2 0.2 0.5 0.5 mA mA ICC1 Power Up Current LS+,LS- and VFr+,VFr- not loaded 12.0 17.0 mA TRANSMISSION CHARACTERISTICS (unless otherwise specified, VCC = 5V + 10%, TA =–5 °Cto 70 °C; typical characteristics are specified at VCC = 5V, TA =25°C, MIC1/2 = 0dBm0,DR = 0dBm0 PCM code, f = 1015.625 Hz; all signal are referenced to GND) AMPLITUDE RESPONSE (Maximum, Nominal, and Minimum Levels) Transmit path - Absolute levels at MIC1 / MIC2 Parameter Test Condition Min. Typ. Max. Unit 0 dBM0 level Transmit Amps connected for 0dB gain 73.9 mVRMS Overload level A law selected 106.08 mVRMS Overload level mu law selected 106.47 mVRMS 0 dBM0 level Transmit Amps connected for 15dB gain 13.14 mVRMS Overload level A law selected 18.86 mVRMS Overload level mu law selected 18.93 mVRMS ST5088 26/33 |
|
