STRAP OPTIONS

30/93

Release 1.5 - January 29, 2002

3.1.3. ADPC STRAP REGISTER 2 CONFIGURATION

Strap2

Access = 0022h/0023h

Regoffset = 04Ch

76543210

See Table

below

Rsv

MD[20]

MD[19]

MD[18]

See Table

below

Rsv

This register defaults to the values sampled on MD pins after reset

Bit Number Sampled

Mnemonic

Description

Bits 7

Rsv

For the parts referenced STPCC4, Reserved

MD[40]

For the parts referenced STPCC5, this bit reflects the value sampled on

MD[40] is used is used to set the clock multiplication factor of the 486

core, as follows:

MD[40]

DX (X1)

DX2 (X2)

This strap is not readable in a register for the STPCC4.

Bit 6-5

Rsv

Reserved

Bits 4

MD[20]

This bit reflects the value sampled on MD[20] pin and controls

the Dot clock (DCLK) source as follows:

0: External. DCLK pin is an input.

1: Internal. DCLK pin is an output and is connected to the

internal frequency synthesizer output. Note this bit is writeable

as well as readable.

Bit 3

Rsv

Reserved

Bit 2

Rsv

Reserved

Bit 1

MD[17]

For the parts referenced STPCC4, see section Section 3.1.1.bits 1:0.

Rsv

For the parts referenced STPCC5.This bit is reserved and not connected

Bit 0

Rsv

Reserved
