H8SX/1663 Datasheet(PDF) 864 Page - Renesas Technology Corp |
|
|
|||||||||||||||||||||||||||||
H8SX/1663 Datasheet(HTML) 864 Page - Renesas Technology Corp |
|
|
864 / 1158 page  Section 16 USB Function Module (USB) Rev.1.00 Jun. 07, 2006 Page 812 of 1102 REJ09B0294-0100 Notes: 1. 2. To protect this LSI from being damaged, use the IC (such as HD74LV-A Series) which can be applied voltage even when the system power is turned off. Prevent noise from the VBUS pin while the USB is performing communication. Vcc VBUS (5 V) Vcc (3.3 V) DrVCC (3.3 V) USD+ D+ VBUS*2 PM4 Vcc *1 Vcc *1 USD- DrVSS Vss GND D- USB connector On-chip transceiver External pull-up control circuit supporting full-speed PULLUP_E USB 1.5 k Ω Figure 16.23 Example of Circuitry in Self Power Mode |
|
