Section 16 USB Function Module (USB)
Rev.1.00 Jun. 07, 2006 Page 815 of 1102
REJ09B0294-0100
16.10.7
Restrictions on Peripheral Module Clock (P
φ) Operating Frequency
Specify the peripheral module clock (P
φ) for the USB at 14 MHz or more. To set the USB
dedicated clock (cku) at 48 MHz, specify the peripheral module clock (P
φ) as shown in table 16.8.
Operation cannot be guaranteed if any frequency other than in the following table is specified.
Table 16.8
Selection of Peripheral Clock (P
φ) when USB is Connected
MD_CLK
EXTAL Input Clock
Frequency
USB Dedicated Clock
(cku: 48 MHz)
P
φ
0
12 MHz
EXTAL
× 4
EXTAL
× 2 (24 MHz)
EXTAL
× 1 (16 MHz)
1
16 MHz
EXTAL
× 3
EXTAL
× 2 (32 MHz)
