902 / 1158 page  Section 18 A/D Converter Rev.1.00 Jun. 07, 2006 Page 850 of 1102 REJ09B0294-0100 Module data bus Control circuit Internal data bus 10-bit A/D Comparator + – Sample-and- hold circuit ADI0 interrupt signal AVCC Vref AVSS AN0 AN1 AN2 AN3 AN4 AN5 AN6 AN7 ADTRG0 Conversion start trigger from the TPU or TMR [Legend] ADCR: A/D control register ADCSR: A/D control/status register ADDRA: A/D data register A ADDRB: A/D data register B ADDRC: A/D data register C ADDRD: A/D data register D ADDRE: A/D data register E ADDRF: A/D data register F ADDRG: A/D data register G ADDRH: A/D data register H Figure 18.1 Block Diagram of A/D Converter |
|
