background image
Section 19 D/A Converter
Rev.1.00 Jun. 07, 2006 Page 870 of 1102
REJ09B0294-0100
Table 19.2
Control of D/A Conversion
Bit 5
DAE
Bit 7
DAOE1
Bit 6
DAOE0
Description
0
0
0
D/A conversion is disabled.
1
D/A conversion of channel 0 is enabled and D/A conversion
of channel 1 is disabled.
Analog output of channel 0 (DA0) is enabled and analog
output of channel 1 (DA1) is disabled.
1
0
D/A conversion of channel 0 is disabled and D/A conversion
of channel 1 is enabled.
Analog output of channel 0 (DA0) is disabled and analog
output of channel 1 (DA1) is enabled.
1
D/A conversion of channels 0 and 1 is enabled.
Analog output of channels 0 and 1 (DA0 and DA1) is
enabled.
1
0
0
D/A conversion of channels 0 and 1 is enabled.
Analog output of channels 0 and 1 (DA0 and DA1) is
disabled.
1
D/A conversion of channels 0 and 1 is enabled.
Analog output of channel 0 (DA0) is enabled and analog
output of channel 1 (DA1) is disabled.
1
0
D/A conversion of channels 0 and 1 is enabled.
Analog output of channel 0 (DA0) is disabled and analog
output of channel 1 (DA1) is enabled.
1
D/A conversion of channels 0 and 1 is enabled.
Analog output of channels 0 and 1 (DA0 and DA1) is
enabled.
