background image
Section 21 Flash Memory (0.18-
µm F-ZTAT Version)
Rev.1.00 Jun. 07, 2006 Page 890 of 1102
REJ09B0294-0100
(5) Flash Transfer Destination Address Register (FTDAR)
FTDAR specifies the start address of the on-chip RAM at which to download an on-chip program.
FTDAR must be set before setting the SCO bit in FCCS to 1.
7
TDER
0
R/W
6
TDA6
0
R/W
5
TDA5
0
R/W
4
TDA4
0
R/W
3
TDA3
0
R/W
0
TDA0
0
R/W
2
TDA2
0
R/W
1
TDA1
0
R/W
Bit
Bit Name
Initial Value
R/W
Bit
Bit Name
Initial
Value
R/W
Description
7
TDER
0
R/W
Transfer Destination Address Setting Error
This bit is set to 1 when an error has occurred in setting
the start address specified by bits TDA6 to TDA0.
A start address error is determined by whether the value
set in bits TDA6 to TDA0 is within the range of H'00 to
H'02 when download is executed by setting the SCO bit
in FCCS to 1. Make sure that this bit is cleared to 0
before setting the SCO bit to 1 and the value specified
by bits TDA6 to TDA0 should be within the range of
H'00 to H'02.
0: The value specified by bits TDA6 to TDA0 is within
the range.
1: The value specified by bits TDA6 to TDA0 is between
H'03 and H'FF and download has stopped.
6
5
4
3
2
1
0
TDA6
TDA5
TDA4
TDA3
TDA2
TDA1
TDA0
0
0
0
0
0
0
0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Transfer Destination Address
Specifies the on-chip RAM start address of the
download destination. A value between H'00 and H'02,
and up to 4 kbytes can be specified as the start address
of the on-chip RAM.
H'00:
H'FF9000 is specified as the start
address.
H'01:
H'FFA000 is specified as the start
address.
H'02:
H'FFB000 is specified as the start
address.
H'03 to H'7F: Setting prohibited.
(Specifying a value from H'03 to H'7F sets
the TDER bit to 1 and stops download of
the on-chip program.)
