background image
Section 21 Flash Memory (0.18-
µm F-ZTAT Version)
Rev.1.00 Jun. 07, 2006 Page 888 of 1102
REJ09B0294-0100
(2) Flash Program Code Select Register (FPCS)
FPCS selects the programming program to be downloaded.
7
0
R
6
0
R
5
0
R
4
0
R
3
0
R
0
PPVS
0
R/W
2
0
R
1
0
R
Bit
Bit Name
Initial Value
R/W
Bit
Bit Name
Initial
Value
R/W
Description
7 to 1
All 0
R
Reserved
These are read-only bits and cannot be modified.
0
PPVS
0
R/W
Program Pulse Verify
Selects the programming program to be downloaded.
0: Programming program is not selected.
[Clearing condition]
When transfer is completed
1: Programming program is selected.
(3) Flash Erase Code Select Register (FECS)
FECS selects the erasing program to be downloaded.
7
0
R
6
0
R
5
0
R
4
0
R
3
0
R
0
EPVB
0
R/W
2
0
R
1
0
R
Bit
Bit Name
Initial Value
R/W
Bit
Bit Name
Initial
Value
R/W
Description
7 to 1
All 0
R
Reserved
These are read-only bits and cannot be modified.
0
EPVB
0
R/W
Erase Pulse Verify Block
Selects the erasing program to be downloaded.
0: Erasing program is not selected.
[Clearing condition]
When transfer is completed
1: Erasing program is selected.
