Section 25 Electrical Characteristics
Rev.1.00 Jun. 07, 2006 Page 1039 of 1102
REJ09B0294-0100
Section 25 Electrical Characteristics
25.1
Absolute Maximum Ratings
Table 25.1
Absolute Maximum Ratings
Item
Symbol
Value
Unit
Power supply voltage
V
CC
PLLV
CC
–0.3 to +4.6
V
Input voltage (except for port 5)
V
in
–0.3 to V
CC +0.3
V
Input voltage (port 5)
V
in
–0.3 to AV
CC +0.3
V
Reference power supply voltage
V
ref
–0.3 to AV
CC +0.3
V
Analog power supply voltage
AV
CC
–0.3 to +4.6
V
Analog input voltage
V
AN
–0.3 to AV
CC +0.3
V
Regular specifications:
–20 to +75*
Operating temperature
T
opr
Wide-range specifications:
–40 to +85*
°C
Storage temperature
T
stg
–55 to +125
°C
Caution:
Permanent damage to the LSI may result if absolute maximum ratings are exceeded.
Note:
*
The operating temperature range during programming/erasing of the flash memory is
0
°C to +75°C for regular specifications and 0°C to +85°C for wide-range specifications.
