background image
Section 19 Serial Communication Interface (SCI, IrDA, CRC)
Rev. 2.00 Sep. 24, 2008 Page 893 of 1468
REJ09B0412-0200
Bit
Bit Name
Initial
Value
R/W
Description
2
TEND
1
R
Transmit End
This bit is set to 1 when no error signal is sent from the
receiving side and the next transmit data is ready to be
transferred to TDR.
[Setting conditions]
• When both the TE and ERS bits in SCR are 0
• When ERS = 0 and TDRE = 1 after a specified time
passed after completion of 1-byte data transfer. The
set timing depends on the register setting as follows:
When GM = 0 and BLK = 0, 2.5 etu after transmission
start
When GM = 0 and BLK = 1, 1.5 etu after transmission
start
When GM = 1 and BLK = 0, 1.0 etu after transmission
start
When GM = 1 and BLK = 1, 1.0 etu after transmission
start
[Clearing conditions]
• When 0 is written to TEND after reading TEND = 1
• When a TXI interrupt request is issued allowing
DMAC or DTC to write the next data to TDR
1
MPB
0
R
Multiprocessor Bit
Not used in smart card interface mode.
0
MPBT
0
R/W
Multiprocessor Bit Transfer
Write 0 to this bit in smart card interface mode.
Note:
*
Only 0 can be written, to clear the flag.
