H8SX/1663R Datasheet(PDF) 1061 Page - Renesas Technology Corp |
|
|
|||||||||||||||||||||||||||||
H8SX/1663R Datasheet(HTML) 1061 Page - Renesas Technology Corp |
|
|
1061 / 1504 page  Section 20 USB Function Module (USB) Rev. 2.00 Sep. 24, 2008 Page 1029 of 1468 REJ09B0412-0200 Notes: 1. 2. To protect this LSI from being damaged, use the IC (such as HD74LV-A Series) which can be applied voltage even when the system power is turned off. Prevent noise from the VBUS pin while the USB is performing communication. Vcc VBUS (5 V) Vcc (3.3 V) DrVcc (3.3 V) USD+ D+ VBUS*2 PM4 Vcc *1 Vcc *1 USD- DrVss Vss GND D- USB connector On-chip transceiver External pull-up control circuit supporting full-speed PULLUP_E USB 1.5 k Ω Figure 20.25 Example of Circuitry in Self Power Mode |
|
