Section 29 List of Registers

Rev. 2.00 Sep. 24, 2008 Page 1294 of 1468

REJ09B0412-0200

Abbreviation

Number

of Bits

Address

Module

Data

Width

Access

Cycles

(Read/Write)

Port F data direction register

PFDDR

H'FFB8E

I/O port

φ/2Pφ

Port 1 input buffer control register

P1ICR

H'FFB90

I/O port

φ/2Pφ

Port 2 input buffer control register

P2ICR

H'FFB91

I/O port

φ/2Pφ

Port 3 input buffer control register

P3ICR

H'FFB92

I/O port

φ/2Pφ

Port 5 input buffer control register

P5ICR

H'FFB94

I/O port

φ/2Pφ

Port 6 input buffer control register

P6ICR

H'FFB95

I/O port

φ/2Pφ

Port A input buffer control register

PAICR

H'FFB99

I/O port

φ/2Pφ

Port B input buffer control register

PBICR

H'FFB9A

I/O port

φ/2Pφ

Port C input buffer control register

PCICR

H'FFB9B

I/O port

φ/2Pφ

Port D input buffer control register

PDICR

H'FFB9C

I/O port

φ/2Pφ

Port E input buffer control register

PEICR

H'FFB9D

I/O port

φ/2Pφ

Port F input buffer control register

PFICR

H'FFB9E

I/O port

φ/2Pφ

Port H register

PORTH

H'FFBA0

I/O port

φ/2Pφ

Port I register

PORTI

H'FFBA1

I/O port

φ/2Pφ

Port J register

PORTJ

H'FFBA2

I/O port

φ/2Pφ

Port K register

PORTK

H'FFBA3

I/O port

φ/2Pφ

Port H data register

PHDR

H'FFBA4

I/O port

φ/2Pφ

Port I data register

PIDR

H'FFBA5

I/O port

φ/2Pφ

Port J data register

PJDR

H'FFBA6

I/O port

φ/2Pφ

Port K data register

PKDR

H'FFBA7

I/O port

φ/2Pφ

Port H data direction register

PHDDR

H'FFBA8

I/O port

φ/2Pφ

Port I data direction register

PIDDR

H'FFBA9

I/O port

φ/2Pφ

Port J data direction register

PJDDR

H'FFBAA

I/O port

φ/2Pφ

Port K data direction register

PKDDR

H'FFBAB

I/O port

φ/2Pφ

Port H input buffer control register

PHICR

H'FFBAC

I/O port

φ/2Pφ

Port I input buffer control register

PIICR

H'FFBAD

I/O port

φ/2Pφ

Port J input buffer control register

PJICR

H'FFBAE

I/O port

φ/2Pφ

Port K input buffer control register

PKICR

H'FFBAF

I/O port

φ/2Pφ

Port D pull-up MOS control register

PDPCR

H'FFBB4

I/O port

φ/2Pφ

Port E pull-up MOS control register

PEPCR

H'FFBB5

I/O port

φ/2Pφ

Port F pull-up MOS control register

PFPCR

H'FFBB6

I/O port

φ/2Pφ
