H8SX/1663R Datasheet(PDF) 1324 Page - Renesas Technology Corp |
|
|
|||||||||||||||||||||||||||||
H8SX/1663R Datasheet(HTML) 1324 Page - Renesas Technology Corp |
|
|
1324 / 1504 page  Section 29 List of Registers Rev. 2.00 Sep. 24, 2008 Page 1292 of 1468 REJ09B0412-0200 Register Name Abbreviation Number of Bits Address Module Data Width Access Cycles (Read/Write) Timer mode register_6 TMDR_6 8 H'FFB11 TPU_6 16 2P φ/2Pφ Timer I/O control register H_6 TIORH_6 8 H'FFB12 TPU_6 16 2P φ/2Pφ Timer I/O control register L_6 TIORL_6 8 H'FFB13 TPU_6 16 2P φ/2Pφ Timer interrupt enable register_6 TIER_6 8 H'FFB14 TPU_6 16 2P φ/2Pφ Timer status register_6 TSR_6 8 H'FFB15 TPU_6 16 2P φ/2Pφ Timer counter_6 TCNT_6 16 H'FFB16 TPU_6 16 2P φ/2Pφ Timer general register A_6 TGRA_6 16 H'FFB18 TPU_6 16 2P φ/2Pφ Timer general register B_6 TGRB_6 16 H'FFB1A TPU_6 16 2P φ/2Pφ Timer general register C_6 TGRC_6 16 H'FFB1C TPU_6 16 2P φ/2Pφ Timer general register D_6 TGRD_6 16 H'FFB1E TPU_6 16 2P φ/2Pφ Timer control register_7 TCR_7 8 H'FFB20 TPU_7 16 2P φ/2Pφ Timer mode register_7 TMDR_7 8 H'FFB21 TPU_7 16 2P φ/2Pφ Timer I/O control register_7 TIOR_7 8 H'FFB22 TPU_7 16 2P φ/2Pφ Timer interrupt enable register_7 TIER_7 8 H'FFB24 TPU_7 16 2P φ/2Pφ Timer status register_7 TSR_7 8 H'FFB25 TPU_7 16 2P φ/2Pφ Timer counter_7 TCNT_7 16 H'FFB26 TPU_7 16 2P φ/2Pφ Timer general register A_7 TGRA_7 16 H'FFB28 TPU_7 16 2P φ/2Pφ Timer general register B_7 TGRB_7 16 H'FFB2A TPU_7 16 2P φ/2Pφ Timer control register_8 TCR_8 8 H'FFB30 TPU_8 16 2P φ/2Pφ Timer mode register_8 TMDR_8 8 H'FFB31 TPU_8 16 2P φ/2Pφ Timer I/O control register_8 TIOR_8 8 H'FFB32 TPU_8 16 2P φ/2Pφ Timer interrupt enable register_8 TIER_8 8 H'FFB34 TPU_8 16 2P φ/2Pφ Timer status register_8 TSR_8 8 H'FFB35 TPU_8 16 2P φ/2Pφ Timer counter_8 TCNT_8 16 H'FFB36 TPU_8 16 2P φ/2Pφ Timer general register A_8 TGRA_8 16 H'FFB38 TPU_8 16 2P φ/2Pφ Timer general register B_8 TGRB_8 16 H'FFB3A TPU_8 16 2P φ/2Pφ Timer control register_9 TCR_9 8 H'FFB40 TPU_9 16 2P φ/2Pφ Timer mode register_9 TMDR_9 8 H'FFB41 TPU_9 16 2P φ/2Pφ Timer I/O control register H_9 TIORH_9 8 H'FFB42 TPU_9 16 2P φ/2Pφ Timer I/O control register L_9 TIORL_9 8 H'FFB43 TPU_9 16 2P φ/2Pφ Timer interrupt enable register_9 TIER_9 8 H'FFB44 TPU_9 16 2P φ/2Pφ |
|
