H8SX/1663R Datasheet(PDF) 1321 Page - Renesas Technology Corp |
|
|
|||||||||||||||||||||||||||||
H8SX/1663R Datasheet(HTML) 1321 Page - Renesas Technology Corp |
|
|
1321 / 1504 page  Section 29 List of Registers Rev. 2.00 Sep. 24, 2008 Page 1289 of 1468 REJ09B0412-0200 Register Name Abbreviation Number of Bits Address Module Data Width Access Cycles (Read/Write) A/D data register C_1 ADDRC_1 16 H'FEA84 A/D_1 16 3P φ/3Pφ A/D data register D_1 ADDRD_1 16 H'FEA86 A/D_1 16 3P φ/3Pφ A/D data register E_1 ADDRE_1 16 H'FEA90 A/D_1 16 3P φ/3Pφ A/D data register F_1 ADDRF_1 16 H'FEA92 A/D_1 16 3P φ/3Pφ A/D data register G_1 ADDRG_1 16 H'FEA94 A/D_1 16 3P φ/3Pφ A/D data register H_1 ADDRH_1 16 H'FEA96 A/D_1 16 3P φ/3Pφ A/D control/status register_1 ADCSR_1 8 H'FEAA0 A/D_1 16 3P φ/3Pφ A/D control register_1 ADCR_1 8 H'FEAA1 A/D_1 16 3P φ/3Pφ Interrupt flag register 0 IFR0 8 H'FEE00 USB 8 3P φ/3Pφ Interrupt flag register 1 IFR1 8 H'FEE01 USB 8 3P φ/3Pφ Interrupt flag register 2 IFR2 8 H'FEE02 USB 8 3P φ/3Pφ Interrupt enable register 0 IER0 8 H'FEE04 USB 8 3P φ/3Pφ Interrupt enable register 1 IER1 8 H'FEE05 USB 8 3P φ/3Pφ Interrupt enable register 2 IER2 8 H'FEE06 USB 8 3P φ/3Pφ Interrupt select register 0 ISR0 8 H'FEE08 USB 8 3P φ/3Pφ Interrupt select register 1 ISR1 8 H'FEE09 USB 8 3P φ/3Pφ Interrupt select register 2 ISR2 8 H'FEE0A USB 8 3P φ/3Pφ EP0i data register EPDR0i 8 H'FEE0C USB 8 3P φ/3Pφ EP0o data register EPDR0o 8 H'FEE0D USB 8 3P φ/3Pφ EP0s data register EPDR0s 8 H'FEE0E USB 8 3P φ/3Pφ EP1 data register EPDR1 8 H'FEE10 USB 8 3P φ/3Pφ EP2 data register EPDR2 8 H'FEE14 USB 8 3P φ/3Pφ EP3 data register EPDR3 8 H'FEE18 USB 8 3P φ/3Pφ EP0o receive data size register EPSZ0o 8 H'FEE24 USB 8 3P φ/3Pφ EP1 receive data size register EPSZ1 8 H'FEE25 USB 8 3P φ/3Pφ Data status register DASTS 8 H'FEE27 USB 8 3P φ/3Pφ FIFO clear register FCLR 8 H'FEE28 USB 8 3P φ/3Pφ End point store register EPSTL 8 H'FEE2A USB 8 3P φ/3Pφ Trigger register TRG 8 H'FEE2C USB 8 3P φ/3Pφ DMA transfer setting register DMA 8 H'FEE2D USB 8 3P φ/3Pφ Configuration value register CVR 8 H'FEE2E USB 8 3P φ/3Pφ |
|
