Section 20 USB Function Module (USB)
Rev. 2.00 Sep. 24, 2008 Page 1012 of 1468
REJ09B0412-0200
20.5.4
Control Transfer
Control transfer consists of three stages: setup, data (not always included), and status (figure
20.11). The data stage comprises a number of bus transactions. Operation flowcharts for each
stage are shown below.
Control-in
Setup stage
Data stage
Status stage
Control-out
No data
SETUP(0)
DATA0
SETUP(0)
DATA0
SETUP(0)
DATA0
IN(1)
DATA1
OUT(1)
DATA1
IN(0)
DATA0
OUT(0)
. . .
. . .
DATA0
IN(0/1)
DATA0/1
OUT(0/1)
DATA0/1
OUT(1)
DATA1
IN(1)
DATA1
IN(1)
DATA1
Figure 20.11 Transfer Stages in Control Transfer
