Section 28 Power-Down Modes
Rev. 2.00 Sep. 24, 2008 Page 1274 of 1468
REJ09B0412-0200
Oscillator
I
φ
NMI
DNMIEG bit
DPSBY bit
NMI exception
handling
DNMIEG = 1
SSBY = 1
DPSBY = 1
SLEEP
instruction
Deep software
standby mode
(power-down mode)
Reset
exception
handling
Internal reset
Oscillation
settling time
IOKEEP bit
DPSRSTF flag
Operated
Retained
Operated
I/O port
Cleared
Cleared
Cleared
Set
NMI interrupt
Set
DNMI interrupt
Becomes invalid
by an internal reset
Set
Set
Set
Figure 28.4 Deep Software Standby Mode Application Example (IOKEEP = 1)
