Section 30 Electrical Characteristics
Rev. 2.00 Sep. 24, 2008 Page 1388 of 1468
REJ09B0412-0200
B
φ
A23 to A0
LUCAS, LLCAS
LUCAS, LLCAS
Read
Write
Note:
Timming of
DACK when DDS = 0 and EDDS = 0
Timming of
RAS when RAST = 0
Tcw is a wait cycle inserted by the programmable wait
Tcwp is a wait cycle inserted by the pin wait
Tp
Tr
Tc1
Tpw
Ttw
Tc2
RAS
OE, RD
WE
D15 to D0
OE, RD
WE
tWTS tWTH
tWTS tWTH
D15 to D0
AS
WAIT
BS
RD/
WR
RD/
WR
(DKC = 0)
DACK3 to DACK0
(DKC = 1)
DACK3 to DACK0
Figure 30.20 DRAM Access Timing: Two-State Access, One Wait
