94 / 113 page  94 AT89C5115 4128G–8051–02/08 Table 69. IPL1 Register IPL1 (S:F8h) Interrupt Priority Low Register 1 Reset Value = XXXX X000b bit addressable 7 6 5 4 3 2 1 0 - - - - - POVRL PADCL - Bit Number Bit Mnemonic Description 7 - Reserved The value read from this bit is indeterminate. Do not set this bit. 6 - Reserved The value read from this bit is indeterminate. Do not set this bit. 5 - Reserved The value read from this bit is indeterminate. Do not set this bit. 4 - Reserved The value read from this bit is indeterminate. Do not set this bit. 3 - Reserved The value read from this bit is indeterminate. Do not set this bit. 2 POVRL Timer Overrun Interrupt Priority Level Less Significant bit Refer to PI2CH for priority level. 1 PADCL ADC Interrupt Priority Level Less Significant bit Refer to PSPIH for priority level. 0 - Reserved The value read from this bit is indeterminate. Do not set this bit. |
|
