SP-48-LR1-RDA Datasheet(PDF) 4 Page - Source Photonics, Inc.

Part # SP-48-LR1-RDA
Description  OC-48 LR-1/STM16 L-16.1 SFP Transceiver
PDF  7 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
Manufacturer  SOURCE [Source Photonics, Inc.]
Direct Link  http://www.sourcephotonics.com
Logo SOURCE - Source Photonics, Inc.

SP-48-LR1-RDA Datasheet(HTML) 4 Page - Source Photonics, Inc.

  SP-48-LR1-RDA Datasheet HTML 1Page - Source Photonics, Inc. SP-48-LR1-RDA Datasheet HTML 2Page - Source Photonics, Inc. SP-48-LR1-RDA Datasheet HTML 3Page - Source Photonics, Inc. SP-48-LR1-RDA Datasheet HTML 4Page - Source Photonics, Inc. SP-48-LR1-RDA Datasheet HTML 5Page - Source Photonics, Inc. SP-48-LR1-RDA Datasheet HTML 6Page - Source Photonics, Inc. SP-48-LR1-RDA Datasheet HTML 7Page - Source Photonics, Inc.
Zoom Inzoom in Zoom Outzoom out
 4 / 7 page
background image
4
OC-48 LR-1/STM16 L-16.1 SFP Transceiver
SP-48-LR1
20550 Nordhoff St. • Chatsworth, CA 91311 • tel: 818.773.9044 • fax: 818.576.9486
9F, No 81, Shui Lee Rd. • Hsinchu, Taiwan, R.O.C. • tel: 886.3.5169222 • fax: 886.3.5169213
LUMINENTOIC.COM
LUMNDS1524-Jul0507
Rev A.1
Pin
Function
Notes
1
VeeT
TX GND
2
TX_FAULT
Open Collector
3
TX_DISABLE
Internally Pulled High
4
MOD_DEF2
Serial Data Input
5
MOD_DEF1
Serial Clock Input
6
MOD_DEF0
Internally Grounded
7
NC
Not Connected
8
LOS
Open Collector
9
VeeR
RX Ground
10
VeeR
RX Ground
11
VeeR
RX Ground
12
RXD-
RX Data Negative
13
RXD+
RX Data Positive
14
VeeR
RX GND
15
VCCR
RX Power
16
VCCT
TX Power
17
VeeT
TX GND
18
TXD+
TX Data Positive
19
TXD-
TX Data Negative
20
VeeT
TX GND
Pinout Definitions
