OC-48 IR1/STM-16 S-16.1 SFP Transceiver

SP-48-IR1

20550 Nordhoff St. • Chatsworth, CA 91311 • tel: 818.773.9044 • fax: 818.576.9486

9F, No 81, Shui Lee Rd. • Hsinchu, Taiwan, R.O.C. • tel: 886.3.5169222 • fax: 886.3.5169213

LUMINENTOIC.COM

LUMNDS258-FEB1706

rev.A.1

Parameter

Symbol

Min

Typical

Max

Unit

Input Differential Impedence

80

100

120

Ω

PECL Single Ended data input swing

250

-

1200

mV

TxFault_Fault

2

-

V

TxFault_Normal

-

V

TxDisable_Disable

2

-

V

TxDisable_Enable

-

V

Transmitter Specifications , Electrical

Parameter

Symbol

Min

Typical

Max

Unit

-

-22

-20

dBm

0

-

-

dBm

Damage Threshold for Receiver

4

-

-

dBm

λ

1260

1310

1360

nm

Maximum Reflectance of Receiver

RX_r

-

-

-27

dB

LOS Assert

-

-30

-

-

dBm

LOS De-assert

-

-

-

-20

dBm

LOS Hysteresis

-

0.5

-

-

dB

Receiver Specifications, Optical

Parameter

Symbol

Min

Typical

Max

Unit

PECL Single Ended Data Output Swing

185

-

800

mV

Data Output Rise Time

-

-

175

ps

Data Output Fall Time

-

-

175

ps

Electrical Output

f) Operational over 1200-1625 nm range
