OC48 IR-2/STM-16 S-16.2 SFP Transceiver

SP-48-IR2

20550 Nordhoff St. • Chatsworth, CA 91311 • tel: 818.773.9044 • fax: 818.576.9486

9F, No 81, Shui Lee Rd. • Hsinchu, Taiwan, R.O.C. • tel: 886.3.5169222 • fax: 886.3.5169213

LUMINENTOIC.COM

LUMNDS1523-Sep2907

Rev.A.1

Features

• Compliant with OC48/STM-16 Standards

• Single 3.3 V supply

• 40 km reach

• 15 dB min, 19.5 typical link budget

• Commerical and Reduced Industrial temperature available

• 1550nm DFB Laser

• SFP MSA SFF-8074i compliant

• GR 253/STM G.957 compliant

• Digital Diagnostic SFF-8472 compliant

• Telcordia GR-468 compliant

• Color Coded Bail Latch Tube: Red

• RoHS compliant

Parameter

Symbol

Min

Typical

Max

Unit

Optical Power

-5

-2.5

0

dBm

Average Launch Power of Off Tx

-

-

-45

dBm

Extinction Ratio

ER

8.2

-

-

dB

Eye Mask

SONET/SDH compliant

Optical Jitter Generation

Jgen

-

-

0.007

UI

-

-

160

ps

-

-

160

ps

Mean Wavelength

λ

1430

1550

1580

nm

Spectral Width (20dB)

∆λ

-

-

1

nm

dp

0.5

1

dB

Relative Intensity Noise

RIN

-

-

-120

dB/Hz

rp

-27

-

-

dB

Transmitter Specifications, Optical

b) 20%-80% values

d) 1dB degradation of receiver sensitivity

Parameter

Symbol

Min.

Typical

Max.

Unit

Supply Voltage

3.135

3.3

3.465

V

Total Current

-

-

300

mA

PSR

100

-

-

Operating Temperature (-Cxx)

-5

-

70

ºC

Operating Temperature (-Rxx)

-20

-

85

ºC

Storage Temperature

-40

-

85

ºC

Data Rate OC48/STM-16

DR

-

2488.32

-

Mbps

a) 20Hz to 155MHz

General operating
