Multi-Rate SFP Transceiver(LR1)

SP-MR-LR1

IMPORTANT NOTICE!

All information contained in this document is subject to change without notice, at LuminentOIC’s sole and absolute discretion. LuminentOIC warrants performance

of its products to current specifications only in accordance with the company’s standard one-year warranty; however, specifications designated as “preliminary” are

given to describe components only, and LuminentOIC expressly disclaims any and all warranties for said products, including express, implied, and statutory warran-

ties, warranties of merchantability, fitness for a particular purpose, and non-infringement of proprietary rights. Please refer to the company’s Terms and Conditions of

Sale for further warranty information.

LuminentOIC assumes no liability for applications assistance, customer product design, software performance, or infringement of patents, services, or intellectual

property described herein. No license, either express or implied, is granted under any patent right, copyright, or intellectual property right, and LuminentOIC makes

no representations or warranties that the product(s) described herein are free from patent, copyright, or intellectual property rights. Products described in this docu-

ment are NOT intended for use in implantation or other life support applications where malfunction may result in injury or death to persons. LuminentOIC customers

using or selling products for use in such applications do so at their own risk and agree to fully defend and indemnify LuminentOIC for any damages resulting from

such use or sale.

THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROVIDED ON AN “AS IS” BASIS. Customer agrees that LuminentOIC is not liable for any

actual, consequential, exemplary, or other damages arising directly or indirectly from any use of the information contained in this document. Customer must contact

LuminentOIC to obtain the latest version of this publication to verify, before placing any order, that the information contained herein is current.

© LuminentOIC, Inc. 2003

All rights reserved

Handling Precautions: This device is susceptible to damage as a result of electrostatic discharge (ESD). A static free environment is highly recommended. Follow

guidelines according to proper ESD procedures.

Laser Safety: Radiation emitted by laser devices can be dangerous to human eyes. Avoid eye exposure to direct or indirect radiation.

Warnings:

Legal Notes:

LUMNDS1529-Oct2907

Rev A.2

Ordering Information

Part numbering Definition:

SP - MR - LR1 - Temperature Diagnostic Revision

• Operating Temperature

C = Commercial (-5 to 70ºC)

R = Reduced Industrial (-20 to 85ºC)

T = Industrial temperature (-40 to 85ºC),

• D = Digital Diagnostic (SFF-8472)

N = No Digital Diagnostic

Available Options:

SP-MR-LR1-CDA

SP-MR-LR1-CNA

SP-MR-LR1-RDA

SP-MR-LR1-RNA

• SP = Small Form Pluggable

MR = Multi Rate

LR1 = Long Reach 40 km

• Design Revision

A = RoHS compliant

SP-MR-LR1-TDA

SP-MR-LR1-TNA
