ADL5604
Rev. 0 | Page 14 of 24
CH1 50mV
Ω
CH2 500mV
Ω M10ns 10GS/s
IT 40ps/pt 25.5ns
A CH2
960mV
D
S
1
2
Figure 34. Turn -On Time, 50% of Control Pulse to 50% of RF Burst
