RF2425
Rev A1 010228
9
Absolute Maximum Ratings
Parameter
Rating
Unit
Supply Voltage
0 to +8.0
VDC
Control Voltage
-1.0 to +6.0
VDC
Input RF Power
+33
dBm
Operating Ambient Temperature
-40 to +85
°C
Storage Temperature
-40 to +150
°C
Parameter
Specification
Unit
Condition
Min.
Typ.
Max.
Overall
T=25 °C, VDD=3.0V, Freq=900MHz
Frequency Range
DC to 2000
MHz
Insertion Loss
0.5
1
dB
Isolation
20
24
dB
CTRL= “Low;” IN1 to OUT2 crosstalk
20
24
dB
CTRL= “High;” IN2 to OUT1 crosstalk
“On” Input VSWR
1:1
Input of active channel
“Off” Input VSWR
100:1
Input of inactive channel (open circuit)
Output P1dB
+31
dBm
Control Logic
CTRL Logic “Low” Voltage
0
V
Channel 1 On, Channel 2 Off
CTRL Logic “High” Voltage
0.7
V
Channel 2 On, Channel 1 Off
Power Supply
Voltage
3
V
Specifications
1.5 to 6
V
Operating Limits
Current
1
2
mA
CTRL= “Low”
2
2.5
mA
CTRL= “High”
Caution! ESD sensitive device.
