BAV19WS ~ BAV21WS

SMALL SIGNAL DIODES

PRV : 100 Volts

Io : 250 mA

FEATURES :

* Silicon Epitaxial Planar Diode

* For General Purpose

* Pb / RoHS Free

MECHANICAL DATA :

* Case : SOD-323 plastic Case

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS

Rating at 25

Parameter

Symbol

BAV19WS

BAV20WS

BAV21WS

Unit

Reverse Voltage

100

150

200

V

Peak Reverse Voltage

120

200

250

V

Rectified Current (Average)

Half Wave Rectification with Resist. Load

Surge Forward Current at t < 1 s and Tj = 25

°C

1.0

A

200

1)

mW

Junction Temperature

Tj

150

°C

Storage Temperature Range

-65 to + 175

°C

°C unless otherwise specified)

Parameter

Symbol

Min.

Typ.

Max.

Unit

-

-

1

V

-

-

1.25

V

Leakage Current

BAV19WS

-

-

100

BAV20WS

-

-

100

BAV21WS

-

-

100

Capacitance

-

-

1.5

pF

Note : 1) Valid provided that electrodes are kept at ambient temperature

Page 1 of 2

Rev. 03 : March 25, 2005

Forward Voltage

50

ns

Reverse Recovery Time

Trr

-

-

250

mA

nA

Test Condition

Dimensions in inches and (millimeters)

SOD-323

0.059 (1.5)

0.043 (1.1)

0.012 (0.3)

min. 0.010 (0.25)
