2 / 8 page ![]() 70N06 Power MOSFET UNISONICTECHNOLOGIESCO.,LTD 2 of 8 www.unisonic.com.tw QW-R502-089.C ABSOLUTE MAXIMUM RATINGS PARAMETER SYMBOL RATINGS UNIT Drain-Source Voltage VDSS 60 V Gate-Source Voltage VGSS ±20 V TC = 25°C 70 A Continuous Drain Current TC = 100°C ID 56 A Drain Current Pulsed (Note 2) IDM 280 A Single Pulsed (Note 3) EAS 600 mJ Avalanche Energy Repetitive (Note 2) EAR 20 mJ Peak Diode Recovery dv/dt (Note 4) dv/dt 10 V/ns Power Dissipation PD 200 W Junction Temperature TJ +150 °C Storage Temperature TSTG -55 ~ +150 °C Notes: 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged. Absolute maximum ratings are stress ratings only and functional device operation is not implied. Repeativity rating: pulse width limited by junction temperature L=0.24mH, IAS=70A, VDD=25V, RG=20Ω, Starting TJ=25°C ISD≤48A, di/dt≤300A/μs, VDD≤BVDSS, Starting TJ=25°C THERMAL DATA PARAMETER SYMBOL RATINGS UNIT Junction to Ambient θJA 62 °C/W Junction to Case θJC 1.2 °C/W ELECTRICAL CHARACTERISTICS (TC =25℃, unless otherwise specified) PARAMETER SYMBOL TEST CONDITIONS MIN TYP MAX UNIT OFF CHARACTERISTICS Drain-Source Breakdown Voltage BVDSS VGS = 0 V, ID = 250 μA 60 V Drain-Source Leakage Current IDSS VDS = 60 V, VGS = 0 V 1 μA Forward VGS = 20V, VDS = 0 V 100 nA Gate-Source Leakage Current Reverse IGSS VGS = -20V, VDS = 0 V -100 nA Breakdown Voltage Temperature Coefficient BV △ DSS/△TJ ID = 1mA, Referenced to 25°C 0.08 V/°C ON CHARACTERISTICS Gate Threshold Voltage VGS(TH) VDS = VGS, ID = 250 μA 2.0 4.0 V Static Drain-Source On-State Resistance RDS(ON) VGS = 10 V, ID = 35 A 12 15 mΩ DYNAMIC CHARACTERISTICS Input Capacitance CISS 3300 pF Output Capacitance COSS 530 pF Reverse Transfer Capacitance CRSS VGS = 0 V, VDS = 25 V f = 1MHz 80 pF SWITCHING CHARACTERISTICS Turn-On Delay Time tD(ON) 12 ns Turn-On Rise Time tR 79 ns Turn-Off Delay Time tD(OFF) 80 ns Turn-Off Fall Time tF VDD = 30V, VGS=10V,ID =70 A (Note 1, 2) 52 ns Total Gate Charge QG 90 140 nC Gate-Source Charge QGS 20 35 nC Gate-Drain Charge (Miller Charge) QGD VDS = 60V, VGS = 10 V, ID = 48A (Note 1, 2) 30 45 nC |
|
|
