LM4862

Preliminary

CMOS IC

UNISONICTECHNOLOGIESCO.,LTD

4 of 5

www.unisonic.com.tw

QW-R502-314.b

ABSOLUTE MAXIMUM RATING (Ta=25°С unless otherwise specified.)

PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage

VDD

6.0

Input Voltage

VIN

-0.3 ~ +(0.3+VDD)

DIP-8

500

Power Dissipation

SOP-8

300

Infrared (15 sec.)

220

°С

Junction Temperature

+150

°С

Storage Temperature

TSTG

-65 ~ +150

°С

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

ELECTRICAL CHARACTERISTICS (VCC=5V, f=1kHz, Ta=25°С unless otherwise specified.)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN TYP MAX UNIT

Supply Voltage

VDD

2.0

5.5

Output Offset Voltage

VOS

VIN=0V

5.0

Quiescent Power Supply Current

IDD

VIN=0V, IO=0A

6.5

12.0

Shutdown Current

ISD

VPIN1=VDD

0.6

µA

THD=1%, f=1kHz, RL=8Ω

500

Output Power

THD=10%, f=1kHz, RL=8Ω

800

Total Harmonic Distortion

THD

f=1kHz, RL=8Ω, Po = 500mW

0.5

Power Supply Rejection Ratio

PSRR

VCC=4.9V ~ 5.1V
