USB0403 - USB0424C

Sot-143 PaCkage inFoRMation

oUtline DiMenSionS

DiM

MilliMeteRS

inCheS

Min

MaX

Min

MaX

A

2.80

3.04

0.110

0.120

B

1.20

1.39

0.047

0.055

C

0.84

1.14

0.033

0.045

D

0.39

0.50

0.015

0.020

F

0.79

0.93

0.031

0.037

G

1.78

2.03

0.070

0.080

J

0.08

0.15

0.003

0.006

K

0.46

0.60

0.018

0.024

L

0.445

0.60

0.0175

0.024

L1

0.40

0.60

0.016

0.024

R

0.72

0.83

0.028

0.033

S

2.11

2.48

0.083

0.098

noteS

1. Dimensioning and tolerances per ANSI Y14.M, 1985.

2. Controlling dimension: inches.

3. Dimensions are exclusive of mold flash and metal burrs.

PaD layoUt DiMenSionS

DiM

MilliMeteRS

inCheS

Min

MaX

Min

MaX

A

1.88

2.13

0.074

0.084

B

1.80

2.06

0.071

0.081

C

0.71

0.97

0.028

0.038

D

0.76

1.02

0.030

0.040

E

1.07

1.32

0.042

0.052

F

0.71

0.97

0.028

0.038

noteS

1. Controlling dimension: inches.

A

G

L

B S

F

D

K

J

C

R

H

L1

A

B

C

D

E

F
