1 / 4 page  Stainless Steel Package Semiconductor Group 1 02.97 Silicon Piezoresistive Relative Pressure Sensor KPY 51-R KPY 56-R Features • Low pressure and temperature hysteresis • Fast response • High sensitivity and linearity • Fatigue free monocrystaline silicon diaphragm giving high load cycle stability • High long term stability • Built in silicon temperature sensor • Media compatible stainless housing Type and Marking Symbol Pressure Range Unit Ordering Code KPY 51 R P 0 … PN 0 … 0.25 bar Q62705-K174 KPY 52 R 0 … 0.6 Q62705-K171 KPY 53 R 0 … 1.6 Q62705-K176 KPY 54 R 0 … 4 Q62705-K178 KPY 55 R 0 … 10 Q62705-K180 KPY 56 R 0 … 25 Q62705-K182 Pin Configuration 1 Capillary tube 2+ V IN 3 − V OUT 4 Temperature sensor (typ. R 25 = 2 kΩ) 5 Temperature sensor 6 − V IN 7+ V OUT 8 Not connected |
