4053L-P16-R datasheet(3/7 Pages) UTC

3 / 7 page

4053

CMOS IC

UNISONICTECHNOLOGIESCO.,LTD

3 of 7

www.unisonic.com.tw

QW-R502-036.D

ABSOLUTE MAXIMUM RATING

PARAMETER

SYMBOL

RATINGS

UNIT

DC Supply Voltage (Referenced to VEE, VSS≧VEE)

VDD

-0.5 ~ +18

Input or Output Voltage (DC or Transient)

(Referenced to VSS for Control Inputs and VEE for Switch I/O)

VIN, VOUT

-0.5 ~ VDD +0.5

Input Current (DC or Transient), per Control Pin

IIN

±10

Switch Through Current

ISW

±25

Power Dissipation

500

Derating above 65°C

mW/°C

Junction Temperature

125

°C

Operating Temperature

TOPR

-40 ~ +125

°C

Storage Temperature

TSTG

-40 ~ +150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

ELECTRICAL CHARACTERISTICS (TA=25°C, unless otherwise specified.)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX UNIT

SUPPLY REQUIREMENTS (Voltages Referenced to VEE)

Power Supply Voltage Range

VDD

VDD – 3≧VSS≧VEE

Quiescent Current per

Package

VDD=5V

Control Inputs: VIN = VSS or VDD

Switch I/O: VEE ≦VI/O ≦VDD,

ΔVSW≦500mV (Note 2)

0.005

µA

VDD=10V

0.010

µA

VDD=15V

0.015

µA

Total Supply Current

(Dynamic Plus Quiescent,

Per Package)

VDD=5V

ID(AV)

TA=25°C only (The channel

component, (VIN-VOUT)/RON, is

excluded)

(0.07 µA/kHz) f + IQ

µA

VDD=10V

(0.20 µA/kHz) f + IQ

µA

VDD=15V

(0.36 µA/kHz) f + IQ

µA

SWITCHES IN/OUT AND COMMONS OUT/IN -- X, Y, Z (Voltages Referenced to VEE)

Recommended Peak–to–Peak Voltage

Into or Out of the Switch

VI/O

Channel On or Off

VDD

VPP

Recommended Static or Dynamic

Voltage Across the Switch (Note2)

ΔVSW

Channel On

600

Output Offset Voltage

VO(OFF) VIN = 0V, No Load

µV

ON Resistance

VDD=5V

RON

ΔVSW≦500mV

VIN = VIL or VIH (Control), and

VIN = 0 to VDD (Switch)

250

1050

Ω

VDD=10V

120

500

Ω

VDD=15V

280

Ω

ON Resistance Between

Any Two Channels in the

Same Package

VDD=5V

ΔRON

Ω

VDD=10V

Ω

VDD=15V

Ω

Off–Channel Leakage Current

IOFF

VIN = VIL or VIH (Control)

Channel to Channel or Any One

Channel, VDD=15V

±0.05

±100

Capacitance, Switch I/O

CI/O

Inhibit = VDD

Capacitance, Common O/I

CO/I

Inhibit = VDD

Capacitance, Feedthrough

(Channel Off)

CI/O

Pins Not Adjacent

0.15

Pins Adjacent

0.47

CONTROL INPUTS – INHIBIT A, B, C (Voltages Referenced to VSS)

Low Level Input Voltage

VDD=5V

VIL

RON= per spec, IOFF = per spec

2.25

1.5

VDD=10V

4.50

3.0

VDD=15V

6.75

4.0

High Level Input Voltage

VDD=5V

VIH

RON= per spec, IOFF = per spec

3.5

2.75

VDD=10V

7.0

5.50

VDD=15V

8.25

Input Leakage Current

ILEAK

VIN= 0 or VDD, VDD=15V

±0.00001

±0.1

µA

Input Capacitance

CIN

5.0

7.5
