2 / 2 page ![]() BAV199W Preliminary DIODE UNISONICTECHNOLOGIESCO.,LTD 2 of 2 www.unisonic.com.tw QW-R601-045.a ABSOLUTE MAXIMUM RATINGS (TA = 25°C, unless otherwise specified) PARAMETER SYMBOL RATINGS UNIT Peak Repetitive Reverse Voltage VRRM 85 V Working Peak Reverse Voltage VRWM 85 V DC Blocking Voltage VR 85 V RMS Reverse Voltage VR(RMS) 60 V Forward Continuous Current Single diode IFM 160 mA Double diode 140 Repetitive Peak Forward Current IFRM 500 mA Non-Repetitive Peak Forward Surge Current @ t = 1.0μs IFSM 4.0 A @ t = 1.0ms 1.0 @ t = 1.0s 0.5 Power Dissipation (Note 2) PD 250 mW Junction Temperature TJ -65~+150 °C Storage Temperature TSTG -65~+150 °C Note: 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged. 1. Absolute maximum ratings are stress ratings only and functional device operation is not implied. 2. Part mounted on FR-4 PC board with recommended pad layout THERMAL DATA PARAMETER SYMBOL RATINGS UNIT Junction to Ambient (Note 2) θJA 500 °C/W ELECTRICAL CHARACTERISTICS (TA =25°C, unless otherwise specified.) PARAMETER SYMBOL TEST CONDITIONS MIN TYP MAX UNIT Reverse Breakdown Voltage (Note 1) V(BR)R IR= 100μA 85 V Forward Voltage (Note 1) VF IF= 1.0mA 0.90 V IF= 10mA 1.0 IF= 50mA 1.1 IF= 150mA 1.25 Leakage Current (Note 1) IR VR= 75V 5.0 nA VR= 75V, TJ= 150°C 80 Total Capacitance CT VR= 0, f = 1.0MHz 2 pF Reverse Recovery Time trr IF= IR= 10mA, Irr = 0.1 x IR,RL= 100Ω 3.0 μs Note: 1. Short duration test pulse to minimize self-heating effect. UTC assumes no responsibility for equipment failures that result from using products at values that exceed, even momentarily, rated values (such as maximum ratings, operating condition ranges, or other parameters) listed in products specifications of any and all UTC products described or contained herein. UTC products are not designed for use in life support appliances, devices or systems where malfunction of these products can be reasonably expected to result in personal injury. Reproduction in whole or in part is prohibited without the prior written consent of the copyright owner. The information presented in this document does not form part of any quotation or contract, is believed to be accurate and reliable and may be changed without notice. |
|
|
