background image
ADL5605
Rev. 0 | Page 4 of 20
Parameter
Test Conditions/Comments
Min
Typ
Max
Unit
POWER-DOWN INTERFACE
DISABLE pin
Logic Level to Enable
VDISABLE decreasing
0
1.1
V
Logic Level to Disable
VDISABLE increasing
1.4
5
V
DISABLE Pin Current
VDISABLE = 5 V
1.4
mA
VCC1 Pin Current1
VDISABLE = 5 V
5.5
mA
Enable Time
10% of control pulse to 90% of RFOUT
75
ns
Disable Time
10% of control pulse to 90% of RFOUT
20
ns
POWER INTERFACE
RFOUT pin
Supply Voltage
4.75
5
5.25
V
Supply Current
307
385
mA
vs. Temperature
−40°C ≤ TA ≤ +85°C
−20/+1
mA
1 VCC1 is the supply to the DUT through the RFOUT pins.
