ADP5024

Data Sheet

Rev. A | Page 6 of 28

INPUT AND OUTPUT CAPACITOR, RECOMMENDED SPECIFICATIONS

Table 4.

Parameter

Symbol

Min

Typ

Max

Unit

NOMINAL INPUT AND OUTPUT CAPACITOR RATINGS

BUCK1, BUCK2 Input Capacitor Ratings

4.7

40

µF

BUCK1, BUCK2 Output Capacitor Ratings

10

40

µF

LDO1 Input and Output Capacitor Ratings

1.0

µF

CAPACITOR ESR

0.001

1

Ω

1

The minimum input and output capacitance should be greater than 0.70 µF over the full range of operating conditions. The full range of operating conditions in the

application must be considered during device selection to ensure that the minimum capacitance specification is met. X7R- and X5R-type capacitors are

recommended; Y5V and Z5U capacitors are not recommended for use because of their poor temperature and dc bias characteristics.
