INTEGRATED CIRCUITS DIVISION

www.ixysic.com

R06

CPC7581

1.7 Additional Electrical Characteristics

Parameter

Conditions

Symbol

Minimum

Typical

Maximum

Unit

Digital input characteristics

Input low voltage

VIL

-2.2

1.5

Input high voltage

VIH

3.5

2.3

Input leakage current

(high)

VDD = 5.5 V, VBAT = -75 V, VIH = 5 V

IIH

-0.1

A

Input leakage current

(low)

VDD = 5.5 V, VBAT = -75 V, VIL = 0 V

IIL

-0.1

Voltage Requirements

VDD

4.5

5.0

5.5

VBAT

-19

-48

-72

BAT is used only for internal protection circuitry. If VBAT goes more positive than -10 V, the device will enter the all-off state and will remain in the all-off state until

the battery goes more negative than -15 V

Power requirements

Power consumption in

talk and all-off states

VDD = 5 V, VBAT = -48 V, measure IDD

and IBAT

-5.5

Power consumption in

ringing state

6.5

VDD current in talk and

all-off states

VDD = 5 V, VBAT = -48 V

IDD

-1.1

2.0

VDD current in ringing

state

-1.3

2.0

VBAT current in any state

IBAT

-0.1

A

Temperature Shutdown Requirements (temperature shutdown flag is active low)

Shutdown activation

temperature

110

125

150

°C

Shutdown circuit

hysteresis

Temperature shutdown requirements are not production tested, but rather guaranteed by design.
