ADP1046AACPZ-R7 Datasheet(PDF) 74 Page - Analog Devices |
|
|
|||||||||||||||||||||||||||||
ADP1046AACPZ-R7 Datasheet(HTML) 74 Page - Analog Devices |
|
|
74 / 88 page  ADP1046A Data Sheet Rev. 0 | Page 74 of 88 Bits Bit Name R/W Description [2:0] Slew rate R/W These bits specify the slew rate at the VS3± pins for the change in the voltage reference setting. Bit 2 Bit 1 Bit 0 Slew Rate 0 0 0 200 mV/ms 0 0 1 100 mV/ms 0 1 0 50 mV/ms 0 1 1 25 mV/ms 1 0 0 12.5 mV/ms 1 0 1 6.25 mV/ms 1 1 0 3.125 mV/ms 1 1 1 1.5625 mV/ms (4 LSB/ms) Table 96. Register 0x60—Normal Mode Digital Filter LF Gain Setting Bits Bit Name R/W Description [7:0] LF gain setting R/W This register determines the low frequency gain of the loop response in normal mode. The LF gain is programmable over a 20 dB range (see Figure 58). Table 97. Register 0x61—Normal Mode Digital Filter Zero Setting Bits Bit Name R/W Description [7:0] Zero setting R/W This register determines the position of the final zero in normal mode (see Figure 58). Table 98. Register 0x62—Normal Mode Digital Filter Pole Setting Bits Bit Name R/W Description [7:0] Pole location R/W This register determines the position of the final pole in normal mode (see Figure 58). Table 99. Register 0x63—Normal Mode Digital Filter HF Gain Setting Bits Bit Name R/W Description [7:0] HF gain setting R/W This register determines the high frequency gain of the loop response in normal mode. The HF gain is programmable over a 20 dB range (see Figure 58). Table 100. Register 0x64—Light Load Mode Digital Filter LF Gain Setting Bits Bit Name R/W Description [7:0] LF gain setting R/W This register determines the low frequency gain of the loop response in light load mode. The LF gain is programmable over a 20 dB range (see Figure 58). Table 101. Register 0x65—Light Load Mode Digital Filter Zero Setting Bits Bit Name R/W Description [7:0] Zero setting R/W This register determines the position of the final zero in light load mode (see Figure 58). Table 102. Register 0x66—Light Load Mode Digital Filter Pole Setting Bits Bit Name R/W Description [7:0] Pole location R/W This register determines the position of the final pole in light load mode (see Figure 58). Table 103. Register 0x67—Light Load Mode Digital Filter HF Gain Setting Bits Bit Name R/W Description [7:0] HF gain setting R/W This register determines the high frequency gain of the loop response in light load mode. The HF gain is programmable over a 20 dB range (see Figure 58). Table 104. Register 0x68—Reserved Bits Bit Name R/W Description [7:0] Reserved R/W Set these bits to 0x00 for proper operation. |
|
