background image
3
Ai7152S
A1 PROs Co., Ltd.
Professional Promotion Process Profit
3. PIN DESCRIPTION
NO
SYMBOL
I/O
DESCRIPTION
1
ADC_D5
I
CCD Image Data 5
2
ADC_D4
I
CCD Image Data 4
3
ADC_D3
I
CCD Image Data 3
4
ADC_D2
I
CCD Image Data 2
5
ADC_D1
I
CCD Image Data 1
6
ADC_D0
I
CCD Image Data 0
7
VSS
G
Digital GND
8
CLPOB
IO
Optical black clamp pulse
9
EXT_9
IO
Pre Blanking pulse / PBLK Out / EXTIO_9
10
ADC_SLD
IO
ADC Serial enable/ External CPU VD
11
ADC_SCL
IO
ADC Serial clock (Camera mode input) / External CPU FLD
12
ADC_SDA
IO
ADC Serial data (Camera mode input) / External CPU HD
13
VDD33
P
3.3V Power
14
I2C_SDA
IO
I2C Data / External CPU Input
15
I2C_SCL
IO
I2C Clock / External CPU Input
16
GPIO5
IO
RX232C TX / External CPU Input
17
GPIO6
I
RX232C RX / External CPU Input
18
RESET_IN
I
System Reset
19
GPIO2
IO
Key Right / External CPU Serial Data Output
20
GPIO4
I
Key Down / External CPU Input
21
GPIO3
I
Key Up / / External CPU Serial Data Input
22
GPIO1
I
Key Left / External CPU Serial Clock
23
GPIO0
I
Key Select / External CPU Chip Select
24
VSS
G
Digital GND
25
XTALO
IO
X-Tal output
26
XTALI
I
X-Tal input (NTSC : 28.6363MHz, PAL : 28.375MHz, 27Mhz)
27
VDD18
P
1.8V Power
28
VDD33
P
3.3V Power
29
VSS
G
Digital GND
30
RSET
I
DAC Register set
