background image
PNP 2N6053
17/10/2012
COMSET SEMICONDUCTORS
2 | 3
ELECTRICAL CHARACTERISTICS
TC=25°C unless otherwise noted
Symbol
Ratings
Test Condition(s)
Min
Typ
MAx Unit
ICEX
Collector Cutoff
Current
VCE= VCEX =-60 V, VBE=1.5 V
2N6053
-
-
-500
µA
VCE= VCEX =-60 V, VBE=1.5 V
TC=150°C
2N6053
-
-
-5
mA
ICEO
Collector Cutoff
Current
VCE=-30 Vdc, IB=0
2N6053
-
-
-0.5
mA
IEBO
Emitter Cutoff
Current
VEB=-5 V
2N6053
-
-
-2.0
mA
VCEO(SUS)
Collector-Emitter
Sustaining Voltage
(*)
IC=-0.1 A
2N6053
-60
-
-
V
VCE(SAT)
Collector-Emitter
saturation Voltage
(*)
IC=-4 A, IB=-16 mA
2N6053
-
-
-2.0
V
IC=-8 A, IB=-80 mA
2N6053
-
-
-3.0
VBE(SAT)
Base-Emitter
Saturation Voltage
(*)
IC=-8 A, IB=-80 mA
2N6053
-
-
-4
V
VBE(ON)
Base-Emitter
Voltage (*)
IC=-4 A, VCE=-3 V
2N6053
-
-
-2.8
V
fT
Transition
Frequency
IC=-3 A, VCE=-3 V, f=1 MHz
2N6053
4
-
-
MHz
hFE
DC Current Gain
(*)
VCE=-3 V, IC=-4 A
2N6053
750
-
18000
-
VCE=-3.0 V, IC=-8 A
2N6053
100
-
-
(*) Pulse Width
≈ 300 µs, Duty Cycle ∠ 2.0%
