INDUC

001-01 / 20130717 / inductor_commercial_power_vlf_en.fm

• All specifications are subject to change without notice.

VLF-M series

VLF252010MT Type

ELECTRICAL CHARACTERISTICS

CHARACTERISTICS SPECIFICATION TABLE

Rated current: smaller value of either Idc1 or Idc2.

Idc1: When based on the inductance change rate (30% below the nominal value)

Idc2: When based on the temperature increase (Temperature increase of 40°C by self heating)

○ Measurement equipment

＊ Equivalent measurement equipment may be used.

Measuring

frequency

(MHz)

DC resistance

(

: )

Rated current(A)

Part No.

max.

typ.

(μH)

Tolerance

max.

typ.

Idc1

Idc2

0.47

±30%

1.0

0.029

0.024

1.84

2.04

3.35

VLF252010MT-R47N

0.68

±30%

1.0

0.043

0.036

1.53

1.70

2.70

VLF252010MT-R68N

1.0

±30%

1.0

0.059

0.049

1.27

1.41

2.25

VLF252010MT-1R0N

1.5

±30%

1.0

0.090

0.075

0.99

1.10

1.83

VLF252010MT-1R5N

2.2

±20%

1.0

0.12

0.10

0.83

0.92

1.47

VLF252010MT-2R2M

3.3

±20%

1.0

0.19

0.16

0.68

0.75

1.15

VLF252010MT-3R3M

4.7

±20%

1.0

0.30

0.25

0.57

0.64

0.95

VLF252010MT-4R7M

6.8

±20%

1.0

0.36

0.30

0.47

0.53

0.85

VLF252010MT-6R8M

10.0

±20%

1.0

0.59

0.49

0.39

0.44

0.66

VLF252010MT-100M

15.0

±20%

1.0

0.87

0.73

0.31

0.34

0.53

VLF252010MT-150M

22.0

±20%

1.0

1.26

1.05

0.26

0.29

0.45

VLF252010MT-220M

Measurement item

Product No.

Manufacturer

4294A

Agilent Technologies

DC resistance

VP-2941A

Panasonic

Rated current Idc1

4285A+42841A+42842C

Agilent Technologies
