Mounting accessories for standard photoelectric, inductive and capacitive sensors

E39, Y92E

Mounting brackets and covers

For cylindrical shapes

Shape

Product

group

Type

Housing material

Features

Applicable sensors

Order code

Mounting

brackets

general purpose -

screw fix

plastic

- cost efficient mounting

bracket

- for M8, M12, M18, M30

- surface mounting

-E3F2

-E2A

Y92E-B8

Y92E-B12

Y92E-B18

Y92E-B30

general purpose -

snap fix

stainless steel

- for dia 20 mm

-E3FZ (snap mount)

E39-EL8

general purpose -

screw fix

-for M18

-E3FZ (mounting with

M18 nuts)

-E3F2

E39-EL12

plastic

- for dia 34 mm

-E2K-C

Y92E-A34

quick access -

snap fix

- snap fix for quick

sensor access

- for M8, M12, M18, M30

- surface mounting

-E3F2

(metal housing)

-E2A

(metal housing)

Y92E-BC8

Y92E-BC12

Y92E-BC18

Y92E-BC30

quick access -

clamp fix

stainless steel

- clamp fix for quick

sensor access with

exact repositioning

- for M8, M12, M18, M30

- through mounting

Y92E-G8

Y92E-G12

Y92E-G18

Y92E-G30
