SPECIFICATION FOR APPROVAL

DOCUMENT

: SRL40000NH

REVISION

: A0

PAGE

: 4 OF 7

Test Item

Condition of Test

Requirements

Load Life

Rated voltage for 1.5 hours followed by a

pause 0.5 hour at 70

± 2℃.

Cycle repeated 1000 hours

Refer to JIS C 5201-1 4.25

∆R : ± (1.0%+0.0005

Ω)

Without distinct damage in

appearance

Damp Heat with Load

± 2℃ with relative humidity 90% to

95%. D.C. rated voltage for 1.5 hours

ON and 30 minutes OFF. Cycle

repeated 1,000 hours

Refer to JIS C 5201-1 4.24

∆R : ± (1.0%+0.0005

Ω)

Without distinct damage in

appearance

Mechanical Shock

100 G’s for 6milliseconds. 5 pulses

Refer to JIS C 5201-1 4.21

∆R : ± (0.5%+0.0005

Ω)

Without mechanical damage such

as break

Bending Test

Glass-Epoxy board thickness : 1.6mm

Bending width : 2mm

Between the fulcrums : 90mm

Refer to JIS C 5201-1 4.33

∆R : ±(1.0%+0.0005

Ω)

Without mechanical damage such

as break
