1 / 6 page  451 Related Information FIBER SENSORS LASER SENSORS PHOTOELECTRIC SENSORS MICRO PHOTOELECTRIC SENSORS AREA SENSORS LIGHT CURTAINS PRESSURE / FLOW SENSORS INDUCTIVE PROXIMITY SENSORS PARTICULAR USE SENSORS SENSOR OPTIONS SIMPLE WIRE-SAVING UNITS WIRE-SAVING SYSTEMS MEASUREMENT SENSORS STATIC CONTROL DEVICES ENDOSCOPE LASER MARKERS PLC / TERMINALS HUMAN MACHINE INTERFACES ENERGY CONSUMPTION VISUALIZATION COMPONENTS FA COMPONENTS MACHINE VISION SYSTEMS UV CURING SYSTEMS Selection Guide U-shaped Convergent Reflective PM-64 PM-24 PM-44/PM-54 Extremely small size and space saving PM-24 series contributes to the miniaturization or space saving of your equipment. Equipped with two independent outputs All models are equipped with two independent outputs- Light-ON and Dark-ON. Hence, one model suffices even if the output is to be used differently, depending upon the location of use. Also, since two independent outputs have been provided, cumbersome handling of the output conversion control input, or fear of logic inversion due to a cable break, is eliminated. The sensor can be connected to the existing wiring as it is. 25.4 mm 1.000 in 22.3 mm 0.878 in 11 mm 0.433 in Previous model 22 mm 0.866 in 12 mm 0.472 in Ultra-small type PM-K24(-R) ( ) Wide model variety A wide variety of 5 shapes and 15 models is available. You may select from this wide range to suit the mounting conditions. Conforming to EMC Directive Recognition PM-24 SERIES Extremely small size enables space saving!! Certified (Some models only) Ultra-small U-shaped Micro Photoelectric Sensor Amplifier Built-in ■General terms and conditions...........F-17 ■Sensor selection guide..................P.441~ Meets global requirements Conforms to Europe’s EMC Directive and obtains UL Recognition. Both, NPN and PNP output models are available. The PM-□24 has also obtained Korea’s S-mark certification. Note: Ensure to insulate the unused output wire. +V 0 V Output 1 (Light-ON) Output 2 (Dark-ON) Connected device side can be left as it is. To PLC Commercial intermediate connector Just connect the cable of the used output (either Light-ON or Dark-ON). Example of connection with a commercial intermediate connector panasonic-electric-works.net/sunx ■Glossaryofterms/Generalprecautions.......P.1359~/P.1405 ■Korea’s S-mark..............................P.1410 |
