QBLP679-XXK_series

PLCC6 LED

---------------------------------------------------------------------------------------------------------------------------------------

Product: QBLP679-XXK_series

Date: March 27, 2014

Page 3 of 12

Version# 2.0

Introduction

Feature:

 Package in tape and reel

 Ultra bright PLCC6

 InGaN technology for IB/IG

 AlInGaP technology for R/Y/O/S

 120 degree viewing angle

Description:

This PLCC6 LEDs have a height profile of 1.60mm.

Combination of high brightness output and robust

package, this LED is ideal for architecture lighting,

status indication, and general application.

Application:

 Status indication

 Industrial equipment backlighting

 Architecture lighting

Certification & Compliance:

 TS16949

 ISO9001

 RoHS Compliant

Dimension:

Units: mm / tolerance = +/-0.2mm
