background image

UNISONIC TECHNOLOGIES CO., LTD

SMBJXXXXX

TVS

www.unisonic.com.tw

1 of 4

Copyright © 2015 Unisonic Technologies Co., Ltd

QW-R229-001.B

SURFACE MOUNT TRANSIENT

VOLTAGE SUPPRESSORS



DESCRIPTION

The UTC SMBJXXXXX is a surface mount transient voltage

supperssors, it uses UTC’s advanced technology to provide

customers with low leakage and very fast response time, etc.



FEATURES

* Low leakage and

* Very fast response time



SYMBOL

SMB

+

-



ORDERING INFORMATION

Ordering Number

Package

Pin Assignment

Packing

Lead Free

Halogen Free

1

2

SMBJXXXXXL-SMB-R

SMBJXXXXXG-SMB-R

SMB

K

A

Tape Reel

Note: Pin Assignment: K: Cathode

A: Anode

(1) R: Tape Reel

(2) SMB: SMB

(3) L: Lead Free, G: Halogen Free

(4) A: 5% uni-directional, CA: 5% Bi-directional

(5) xxx: refer to ELECTRICAL CHARACTERISTICS

SMBJXXXXXL-SMB-R

(1)Packing Type

(2)Package Type

(3)Halogen Free

(4)Category

(5)Output Voltage Code



MARKING

Date Code

Voltage Code

Cathode Band for

uni-directional Only

UTC

SMBJXXXXX

Category
