UTM3023
Power MOSFET
UNISONICTECHNOLOGIESCO.,LTD
2 of 5
www.unisonic.com.tw
QW-R502-178.B
ABSOLUTE MAXIMUM RATINGS (TA = 25°C, unless otherwise specified)
PARAMETER
SYMBOL
RATINGS
UNIT
Drain-Source Voltage
VDSS
30
V
Gate-Source Voltage
VGSS
±20
Maximum Continuous Drain Current
ID
30
A
Maximum Pulsed Drain Current
IDM
70
Maximum Power Dissipation
PD
62.5
W
Maximum Junction Temperature
TJ
150
°C
Storage Temperature Range
TSTG
-55 ~ +150
Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
ELECTRICAL CHARACTERISTICS (TJ =25°C, unless otherwise noted)
PARAMETER
SYMBOL
TEST CONDITIONS
MIN
TYP MAX UNIT
OFF CHARACTERISTICS
Drain-Source Breakdown Voltage
BVDSS
VGS =0 V, IDS =250µA
30
V
Drain-Source Leakage Current
IDSS
VDS =24 V, VGS =0 V
1
µA
Gate-Source Leakage Current
IGSS
VDS =0 V, VGS = ±20V
±100
nA
ON CHARACTERISTICS
Gate Threshold Voltage
VGS(TH) VDS =VGS, IDS =250 µA
1
1.5
2
V
Drain-Source On-State Resistance(Note 2)
RDS(ON)
VGS =10 V, IDS =20 A
15
20
mΩ
VGS =5 V, IDS =10 A
22
28
DYNAMIC CHARACTERISTICS
Input Capacitance
CISS
VDS =15 V, VGS =0V, f=1.0MHz
1200
pF
Output Capacitance
COSS
220
Reverse Transfer Capacitance
CRSS
100
SWITCHING CHARACTERISTICS
Turn-ON Delay Time (Note 2)
tD(ON)
IDS=2 A,VDD=15 V,RG=6 Ω,
VGEN =10V
11
18
ns
Turn-ON Rise Time
tR
17
26
Turn-OFF Delay Time
tD(OFF)
37
54
Turn-OFF Fall Time
tF
20
30
Total Gate Charge (Note 2)
QG
VDS =15V, VGS =5V, IDS =10A
15
20
nC
Gate-Source Charge
QGS
5.8
Gate-Drain Charge
QGD
3.8
SOURCE- DRAIN DIODE RATINGS AND CHARACTERISTICS
Drain-Source Diode Forward Voltage(Note2)
VSD
ISD=15A,VGS=0V
0.7
1.3
V
Note: 1. Pulse width limited by TJ(MAX)
2. Pulse width ≤300us, duty cycle ≤2%
3. Surface Mounted on FR4 Board, t ≤ 10 sec.
