background image
BAV70W
DIODE
UNISONICTECHNOLOGIESCO.,LTD
2 of 3
www.unisonic.com.tw
QW-R601-038.C
ABSOLUTE MAXIMUM RATINGS (TA = 25°C unless otherwise specified)
PARAMETER
SYMBOL
RATINGS
UNIT
Non-Repetitive Reverse Voltage
VRM
100
V
Peak Repetitive Reverse Voltage
VRRM
75
V
Working Peak Reverse Voltage
VRWM
75
V
DC Blocking Voltage
VR
75
V
RMS Reverse Voltage
VR(RMS)
53
V
Forward Continuous Current
IFM
300
mA
Average Rectified Output Current
IO
150
mA
Non-Repetitive Peak Forward Surge
Current
@ t = 1.0μs
IFSM
2.0
A
@ t = 1.0s
1.0
Power Dissipation
PD
200
mW
Operating Temperature
TJ
-65~+150
°C
Storage Temperature
TSTG
-65~+150
°C
Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
THERMAL DATA
PARAMETER
SYMBOL
RATINGS
UNIT
Thermal Resistance Junction to Ambient Air
θJA
625
°C/W
ELECTRICAL CHARACTERISTICS (TA =25°C unless otherwise specified.)
PARAMETER
SYMBOL
TEST CONDITIONS
MIN TYP MAX UNIT
Reverse Breakdown Voltage (Note)
V(BR)R
IR= 100μA
75
V
Forward Voltage
VF
IF= 1.0mA
0.715
V
IF= 10mA
0.855
IF= 50mA
1.0
IF= 150mA
1.25
Reverse Current (Note 1)
IR
VR= 75V
2.5
μA
VR= 75V, TJ= 150°C
50
VR= 25V, TJ= 150°C
30
VR=20V
25
nA
Total Capacitance
CT
VR= 0, f = 1.0MHz
2.0
pF
Reverse Recovery Time
trr
IF= IR= 10mA, Irr = 0.1 x IR,
RL= 100Ω
4.0
ns
Notes: Short duration test pulse used to minimize self-heating effect.
