MBR1060CL-TQ2-R Datasheet(PDF) 1 Page - Unisonic Technologies |
|
|
|||||||||||||||||||||||||||||
MBR1060CL-TQ2-R Datasheet(HTML) 1 Page - Unisonic Technologies |
|
|
1 / 3 page  UNISONIC TECHNOLOGIES CO., LTD MBR1060C DIODE www.unisonic.com.tw 1 of 3 Copyright © 2015 Unisonic Technologies Co., Ltd QW-R601-019. E 10A SCHOTTKY BARRIER RECTIFIER DIODES FEATURES * Schottky Barrier Chip * Guard Ring Die Construction for Transient Protection * Low Power Loss, High Efficiency * High Surge Capability * High Current Capability and Low Forward Voltage Drop * For Use in Low Voltage, High Frequency Inverters, Free * Wheeling, and Polarity Protection Applications SYMBOL ORDERING INFORMATION Ordering Number Package Pin Assignment Packing Lead Free Halogen Free 1 2 3 MBR1060CL-TA3-T MBR1060CG-TA3-T TO-220 A K A Tube MBR1060CL-TF3-T MBR1060CG-TF3-T TO-220F A K A Tube MBR1060CL-TF1-T MBR1060CG-TF1-T TO-220F1 A K A Tube MBR1060CL-TQ2-T MBR1060CG-TQ2-T TO-263 A K A Tube MBR1060CL-TQ2-R MBR1060CG-TQ2-R TO-263 A K A Tape Reel Note: Pin Assignment: A: Anode K: Cathode MARKING |
