Product Details

Thermal Performance

ATS PART # ATS-1184-C1-R0

Features & Benefits

Eighth Brick DC-DC Converter

REV2_0114

AIR VELOCITY

THERMAL RESISTANCE

FT/MIN

M/S

°C/W (UNDUCTED FLOW)

°C/W (DUCTED FLOW)

200

1.0

6.65

4.59

300

1.5

5.35

400

2.0

4.63

500

2.5

4.16

600

3.0

3.81

700

3.5

3.54

800

4.0

3.32

pressure drop and more surface area that maximizes

the effective convection (air) cooling

material

(M3 Philips Pan Head) at 5, 6 and 8 mm lengths

*Image is for illustration purposes only.

Assembly Part Number

Length (mm)

4 Screws per Set

ATS-1184-C2-R0

5

ATS-1184-C3-R0

6

ATS-1184-C4-R0

8

DIMENSION

A

DIMENSION

B

DIMENSION

C

DIMENSION

D

DIMENSION

E

DIMENSION

F

DIMENSION

G

DIMENSION

H

DIMENSION

I

INTERFACE

MATERIAL

FINISH

T766

GOLD

ANODIZED

NOTES:

1)

Thermal performance data are provided for reference only. Actual performance may vary

by application.

2)

ATS reserves the right to update or change its products without notice to improve the

design or performance.

3)

Standard lead time is 4-6 weeks ARO.

4)

Contact ATS to learn about custom options available.

5)

Dimension D = heat sink height from bottom of the base to the top of the fin field.

6)

Dimension E = Hole Width

7)

Dimension F = Hole Length

8)

Dimension G = Short Hole Width

9)

Dimension H = Short Hole Length

10) Dimension I = Center Hole
