EM358x

Rev 1.0

1. Related Documents and Conventions

1.1. Related Documents

This data sheet accompanies several documents to provide the complete description of the Ember EM358x

devices.

1.1.1. Ember EM358x Reference Manual

The Silicon Laboratories Ember EM358x Reference Manual provides the detailed description for each peripheral

on the EM358x devices.

1.1.2. ZigBee Specification

The core ZigBee specification (Document 053474) defines ZigBee's smart, cost-effective and energy-efficient

mesh network. It can be downloaded from the ZigBee website (www.zigbee.org). ZigBee Alliance membership is

required.

1.1.3. ZigBee PRO Stack Profile

The ZigBee PRO Stack Profile specification (Document 074855) is optimized for low power consumption and to

support large networks with thousands of devices. It can be downloaded from the ZigBee website (111.zigbee.org).

ZigBee Alliance membership is required.

1.1.4. ZigBee Stack Profile

The ZigBee Stack Profile specification (Document 064321) is designed to support smaller networks with hundreds

of devices in a single network. It can be downloaded from the ZigBee website (111.zigbee.org). ZigBee Alliance

membership is required.

1.1.5. Bluetooth Core Specification

The Bluetooth specification is the global short-range wireless standard enabling connectivity for a broad range of

electronic devices. Version 2.1 + EDR (Enhanced Data Rate) can be found here:

http://www.bluetooth.org/docman/handlers/downloaddoc.ashx?doc_id=241363

1.1.6. EEE 802.15.4-2003

This standard defines the protocol and compatible interconnection for data communication devices using low data

rate, low power and low complexity, short-range radio frequency (RF) transmissions in a wireless personal area

network (WPAN). It can be found here:

IEEE 802.15.4-2003 (http://standards.ieee.org/getieee802/download/802.15.4-2003.pdf)

1.1.7. EEE 802.11g

This version provides changes and additions to support the further higher data rate extension for operation in the

2.4 GHz band. It can be found here:

http://standards.ieee.org/getieee802/download/802.11g-2003.pdf

1.1.8. USB 2.0 Specification

The Universal Serial Bus Revision 2.0 specification provides the technical details to understand USB requirements

and design USB compatible products. The main specification (usb_20.pdf) is part of the zipfile found here:

http://www.usb.org/developers/docs/usb_20_101111.zip

1.1.9. ARM® Cortex™-M3 Reference Manual

ARM-specific features like the Nested Vector Interrupt Controller are described in the ARM® Cortex™-M3

reference documentation. The online reference manual can be found here:

http://infocenter.arm.com/help/topic/com.arm.doc.subset.cortexm.m3/index.html#cortexm3
