Electrical characteristics

HVLED002

6/19

DocID028720 Rev 1

Electrical characteristics

Unless otherwise stated, these specifications apply for 0 ≤ Tamb ≤ 85 °C; Vi = 15 V;

RT = 10 K; CT = 3.3 nF(a).

a. Max. package power dissipation limits must be respected; low duty cycle pulse techniques are used during the test

maintaining TJ as close to Tamb as possible.

Table 5. Electrical characteristics

Symbol

Parameter

Test conditions

Min.

Typ.

Max.

Unit

SUPPLY VOLTAGE

Max. operative volt.

REFERENCE SECTION

VREF

Output voltage

TJ = 25 °C, Io = 1 mA

4.95

5.00

5.05

VREF

Line regulation

12 V ≤ Vi ≤ 25 V

VREF

Load regulation

1 ≤ Io ≤ 20 mA

VREF/T Temperature stability

(1)

0.2

mV/°C

Total output variation

Line, load, temperature

4.82

5.18

Output noise voltage

10 Hz ≤ f ≤ 10 KHz, Tj = 25 °C(1)

µV

Long term stability

Tamb = 125 °C, 1000 hrs(1)

525

ISC

Output short-circuit

-30

-100

-180

OSCILLATOR SECTION

fOSC

Frequency

TJ = 25 °C

TA = 0 to 85 °C

TJ = 25 °C (RT = 6.2 k, CT = 1 nF)

225

250

275

KHz

fOSC/V Frequency change with volt.

VCC = 12 V to 25 V

0.2

fOSC/T Frequency change with temp.

Tamb = 0 °C to 85 °C

0.5

VOSC

Oscillator voltage swing

Peak-to-peak

1.6

Idischg

Discharge current (VOSC = 2 V) TJ = 25 °C

7.8

8.3

8.8

TA = 0°C to 85°C

7.6

8.8

ERROR AMPLIFIER SECTION

VREF,EA Input voltage

V(COMP) = 2.5 V

2.42

2.50

2.58

Input bias current

VFB = 5 V

-0.1

-2

µA

AVOL

2 V ≤ Vo ≤ 4 V

Unity gain bandwidth

TJ = 25 °C(1)

0.7

MHz

PSRR

Power supply reject. ratio

12 V ≤ Vi ≤ 25 V

Output sink current

V(VFB) = 2.7 V, V(COMP) = 1.1 V
