INCHANGE Semiconductor

isc RF Product Specification

isc website：www.iscsemi.cn

isc Silicon NPN RF Transistor

2SC3582

S-PARAMETER

VCE = 8 V, IC = 5 mA, ZO = 50Ω

f (MHz)

︱

S11︱

∠

S11

︱

S21︱

∠

S21

︱

S12︱

∠

S12

︱

S22︱

∠

S22

200

0.668

-45.8

11.385

128.9

0.049

83.5

0.833

-26.9

400

0.425

-61.5

7.014

103.7

0.063

76.3

0.681

-31.1

600

0.294

-73.2

5.189

88.6

0.088

68.5

0.620

-36.0

800

0.214

-79.4

3.967

75.4

0.103

64.5

0.580

-40.8

1000

0.167

-79.5

3.485

64.7

0.123

60.8

0.561

-46.3

1200

0.132

-79.8

2.831

57.0

0.147

55.9

0.549

-53.4

1400

0.098

-75.2

2.604

48.5

0.175

50.7

0.561

-60.3

1600

0.073

-72.0

2.182

39.1

0.192

47.9

0.573

-69.1

1800

0.071

-63.7

2.135

31.0

0.215

44.2

0.595

-71.8

2000

0.070

-60.6

1.879

21.6

0.221

38.0

0.617

-78.0
